Drawing markup
Your architectural set, returned with the lighting plan, the load plan and the device positions marked on it.
Ask for this one first.
Home/For the trade/Drawing support
Drawing support.
A markup of your own drawing set, cut sheets for the devices going on the wall, and the rough-in detail the electrician needs. Ask for what you need and we send it.
Downloads
Cut sheets and rough-in guides are sent on request.
Keypad and shade cut sheets and rough-in guides are prepared for each project and sent by email, matched to the products and finishes on your job.
What we send you.
Product cut sheets
Cut sheets and dimensions for the keypads, plates, shades and speakers under consideration, in the finishes actually available.
Per project, not a catalog.
Rough-in guidance
Back box depths, bracket types, wiring can positions and the home runs each device needs, so the rough-in is right the first time.
Written for whoever is on site.
Tell us what you need.
We reply within two business days.
